We are leading automatic power factor correction panel (APFC Control Panel) manufacturer which is used to improve the power factor, whenever required, by switching ON and OFF the required capacitor bank units automatically. APFC Panel is provided for controlling the power factor, where the front of the fully compartmentalized feeder for controlling individual capacitors, where as rear side house Capacitors in a well ventilated panel area.

APFC with microprocessor based relays for controlling power factor to desired values.

RTPFC Panels using Thyristor based capacitor switching.

APFC Control Panel Technical Features

Construction Details

• Modular / Non-compartmentalized construction.
• Panel structure with MS CRCA/SS.
• Indoor / Outdoor type Structure.
• Single front/double front Operated.
• Provision for Extensible for future use.
• Provision of Rubber Gaskets to meet IP requirement like IP-42/52/54/55/65.
• Arrangement for heat dissipation by means of Exhaust Fan or Lowers.

Pre Treatment & Painting

• Three Tank / Seven Tank Pre treatment process.
• Final paint shade as per SI or client specifications.
• Synthetic Enamel / Epoxy based primer / Powder coating as per customer's requirement.

Bus Bar Arrangement & Cable Alley

• Electrical Grade Aluminum / Copper Busbar.
• Main busbar on top / bottom of the Panel.
• Separate chamber for vertical dropper.
• Busbar supports of SMC/DMC Material.
• Busbar System design on basis of continuous Current rating and Fault level with stand capacity.
• Allowable temperature rise as per IS 8623 or as per specifications.
• Top / Bottom cable entry. Detachable gland plate for cable entry.

Assembly & Wiring

• Selection of components from Approved / Reputed vendor list as per Approved Drawing.
• Design of Internal Layout to optimum usage of space.
• Internal wiring with 660/1100 V Grade PVC coated stranded Copper Flexible Wires.
• Crimping Lugs are used for internal Connections / Terminations.

Quality Assurance & Control Systems

• Inspection of Fabrication structure for dimension as per approved G.A. drawing.
• Inspection of Painting / Powder coating.
